T2 UPSafety

Sync Offstreet permits directly with UPSafety’s handheld enforcement platform

Offstreet integrates with T2 UPSafety to automatically push permit data into your enforcement system. Once connected, enforcement officers will see valid permits in real time—no manual entry required.

Integration Overview

This is a push integration. Offstreet syncs licence plates to T2 UPSafety using secure credentials. Each Offstreet location is mapped to a Zone Code in UPSafety, ensuring permits are routed to the correct enforcement zone.

What You’ll Need

Requirement	Description	Who Provides It
API Key	Authenticates Offstreet’s connection to UPSafety	You (via T2)
Client ID	Identifies your UPSafety account	You (via T2)
Zone Code(s)	Tied to each enforcement location in UPSafety	You or Offstreet
Company ID / Name	Used internally for Offstreet setup and tracking	Offstreet
Location ID / Name	Used to configure each location within Offstreet	Offstreet

Authentication is managed by Offstreet using the credentials provided by T2.No client-side configuration is required once credentials are submitted.

Step-by-Step Setup

1. Request Credentials from T2

Contact your T2 Account Manager and request the following credentials:

API Key
Client ID
Zone Code(s) for each enforcement location

Suggested Email Template:

plain text

Hi [T2 Contact Name], We’re working with Offstreet to set up an integration with UPSafety. Could you please provide the following credentials for our account? - API Key - Client ID - Zone Code(s) for each location Once we receive those, Offstreet will complete the configuration. Thanks, [Your Name]

2. Offstreet Configures the Integration

Set up the integration in our system
Connect your company and each location to UPSafety using the Zone Codes
Coordinate backend setup with our engineering team

3. Map Zone Codes in Offstreet

After the integration is configured:

Offstreet will map each Zone Code to your corresponding location
You’ll see these mappings reflected in the Zone Name field in your Offstreet dashboard
This mapping ensures that permit data routes correctly to UPSafety

Zone Codes must match exactly—these are case-sensitive and critical for permit delivery.

4. Test the Integration

Once mappings are complete:

Offstreet will register a test permit (e.g., plate TEST123)
You or your T2 contact will confirm that the plate appears correctly in UPSafety

Once confirmed, the integration is live.

Troubleshooting Tips

Issue	What to Check
Test plate not appearing in UPSafety	Confirm the Zone Code was entered correctly in Offstreet (case-sensitive)
Permit shows as “Delivered” but is missing	Double-check API Key and Client ID are correct and active
Errors during setup	Offstreet will work with T2 and engineering to troubleshoot using logs

Need Help?

T2 UPSafety Support: Contact your T2 UPSafety Account Represenative or email upsafety.support@t2systems.com
Offstreet Support: Reach out to your Offstreet Account Manager or Contact Support
